Symbols are common in flow charts

share



Various symbols that can be used to build a flow chart.

  • ellipse Start / End
  • rectangle Process
  • Rectangle with vertical lines - Predefined process (usually the content of the process will be detailed in a separate diagram)
  • rhombus Junction for decision
  • parallelogram - input / output data
  • A rectangle with a wavy base Document
  • Galilee Database / database / database
  • trapeze upside down Manual operation
  • hexagon Wide base Preparation
